7HQK | pdb_00007hqk

PanDDA analysis group deposition -- Crystal structure of SARS-CoV-2 NSP3 macrodomain in complex with CACHE3HI_1702_58

PDB DOI: https://doi.org/10.2210/pdb7HQK/pdb
Deposition Group: G_1002327 (changed state) ExploreG_1002327

Classification: VIRAL PROTEIN
Organism(s): Severe acute respiratory syndrome coronavirus 2
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-12-08 Released: 2025-08-20
Deposition Author(s): Correy, G.J., Fraser, J.S.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.00 Å
R-Value Free:
0.166 (Depositor), 0.174 (DCC)
R-Value Work:
0.149 (Depositor), 0.160 (DCC)
R-Value Observed:
0.150 (Depositor)

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Ligand screen against SARS-CoV-2 NSP3 macrodomain

Correy, G.J., Fraser, J.S.

To be published.

Macromolecule Content

Total Structure Weight: 36.73 kDa
Atom Count: 3,857
Modeled Residue Count: 336
Deposited Residue Count: 338
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Non-structural protein 3	A, B	169	Severe acute respiratory syndrome coronavirus 2	Mutation(s): 0 Gene Names: rep, 1a-1b EC: 3.4.22
UniProt
Find proteins for P0DTD1 (Severe acute respiratory syndrome coronavirus 2) Explore P0DTD1 Go to UniProtKB: P0DTD1
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0DTD1
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1BJX (Subject of Investigation/LOI) Query on A1BJX Download Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	N'-(3,5-dichloro-4-methylbenzene-1-sulfonyl)-2-hydroxybenzohydrazide C₁₄ H₁₂ Cl₂ N₂ O₄ S FYJRXAXEURZPJA-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.00 Å
R-Value Free: 0.166 (Depositor), 0.174 (DCC)
R-Value Work: 0.149 (Depositor), 0.160 (DCC)
R-Value Observed: 0.150 (Depositor)

Space Group: P 4₃

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 88.75	α = 90
b = 88.75	β = 90
c = 39.349	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
XDS	data reduction
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-08-20

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	U19AI171110

Revision History (Full details and data files)

Version 1.0: 2025-08-20
Type: Initial release
