9A1B | pdb_00009a1b

CS-Rosetta structure of engineered IgG-binding domain of protein G (GB) - model A1

• PDB DOI: https://doi.org/10.2210/pdb9A1B/pdb

• Mutation(s): No


• Deposited: 2021-04-21 Released: 2022-06-24
• Deposition Author(s): He Y, Chen Y, Ruan B, Choi EJ, Chen Y, Motabar D, Solomon T, Simmerman R, Kauffman T, Gallagher DT, Bryan PN, Orban J

---

Integrative Structure Snapshot

• Multi-Scale: No
• Multi-State: No
• Ordered-State: No
• Deposited Models: 10
• Representative Model: 1

Literature

Design and characterization of a protein fold switching network

Ruan B, He Y, Chen Y, Choi EJ, Chen Y, Motabar D, Solomon T, Simmerman R, Kauffman T, Gallagher DT, Orban J, Bryan PN

(2023) Nat Commun 14: 431

• PubMed: 36702827
• DOI: https://doi.org/10.1038/s41467-023-36065-3
• Primary Citation of Related Structures:
  7MN1, 7MN2, 7MP7, 7MQ4, 9A1B, 9A1C, 9A1D


• PubMed Abstract:


  To better understand how amino acid sequence encodes protein structure, we engineered mutational pathways that connect three common folds (3α, β-grasp, and α/β-plait). The structures of proteins at high sequence-identity intersections in the pathways (nodes) were determined using NMR spectroscopy and analyzed for stability and function. To generate nodes, the amino acid sequence encoding a smaller fold is embedded in the structure of an ~50% larger fold and a new sequence compatible with two sets of native interactions is designed. This generates protein pairs with a 3α or β-grasp fold in the smaller form but an α/β-plait fold in the larger form. Further, embedding smaller antagonistic folds creates critical states in the larger folds such that single amino acid substitutions can switch both their fold and function. The results help explain the underlying ambiguity in the protein folding code and show that new protein structures can evolve via abrupt fold switching.

---

Organizational Affiliation:
• Potomac Affinity Proteins, 11305 Dunleith Pl, North Potomac, MD, 20878, USA.
Institute for Bioscience and Biotechnology Research, University of Maryland, 9600 Gudelsky Drive, Rockville, MD, 20850, USA.
Department of Bioengineering, University of Maryland, College Park, MD, 20742, USA.
Department of Chemistry and Biochemistry, University of Maryland, College Park, MD, 20742, USA.
National Institute of Standards and Technology and the University of Maryland, 9600 Gudelsky Drive, Rockville, MD, 20850, USA.
Institute for Bioscience and Biotechnology Research, University of Maryland, 9600 Gudelsky Drive, Rockville, MD, 20850, USA. [e-mail].
Department of Chemistry and Biochemistry, University of Maryland, College Park, MD, 20742, USA. [e-mail].
Potomac Affinity Proteins, 11305 Dunleith Pl, North Potomac, MD, 20878, USA. [e-mail].
Institute for Bioscience and Biotechnology Research, University of Maryland, 9600 Gudelsky Drive, Rockville, MD, 20850, USA. [e-mail].

Assembly

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Macromolecule Content

• Total Structure Weight: 7.2 kDa
• Atom Count: 437
• Modeled Residue Count: 56
• Deposited Residue Count: 56
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Immunoglobulin G-binding protein G	A	56	N/A	Mutation(s): 0

Experimental Data & Validation

Integrative Structure Snapshot

• Multi-Scale: No
• Multi-State: No
• Ordered-State: No
• Deposited Models: 10
• Representative Model: 1

Structure Validation

View Full Validation Report

View Summary Validation Report

Entry History

Deposition Data

• Released Date: 2022-06-24
Deposition Author(s): He Y, Chen Y, Ruan B, Choi EJ, Chen Y, Motabar D, Solomon T, Simmerman R, Kauffman T, Gallagher DT, Bryan PN, Orban J

Revision History

• Version 1.0: 2022-06-24
  Type: Initial release
