9O4L | pdb_00009o4l

Crystal structure of Human p38 alpha MAPK in Complex with MW01-8 -066WH

• PDB DOI: https://doi.org/10.2210/pdb9O4L/pdb

• Classification: TRANSFERASE/TRANSFERASE INHIBITOR
• Organism(s): Homo sapiens
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2025-04-08 Released: 2025-04-30
• Deposition Author(s): Brunzelle, J.S., Shuvalova, L., Roy, S.M., Watterson, D.M.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.27 Å
• R-Value Free:
  0.241 (Depositor), 0.241 (DCC)
• R-Value Work:
  0.190 (Depositor), 0.194 (DCC)
• R-Value Observed:
  0.193 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Human p38 alpha MAPK in Complex with MW01-8 -066WH

Brunzelle, J.S., Shuvalova, L., Roy, S.M., Watterson, D.M.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Macromolecule Content

• Total Structure Weight: 44.66 kDa
• Atom Count: 2,846
• Modeled Residue Count: 334
• Deposited Residue Count: 384
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Mitogen-activated protein kinase 14	A	384	Homo sapiens	Mutation(s): 0  Gene Names: MAPK14, CSBP, CSBP1, CSBP2, CSPB1, MXI2, SAPK2A EC: 2.7.11.24
UniProt & NIH Common Fund Data Resources
Find proteins for Q16539 (Homo sapiens) Explore Q16539  Go to UniProtKB:  Q16539
PHAROS:  Q16539 GTEx:  ENSG00000112062

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
A1B8B (Subject of Investigation/LOI)	C [auth A]	6-(4-methylpiperazin-1-yl)-3-phenyl-4-(pyridin-4-yl)pyridazine C20 H21 N5 CXPCCLCRWYXEET-UHFFFAOYSA-N
GG5	B [auth A]	4-[3-(4-FLUOROPHENYL)-1H-PYRAZOL-4-YL]PYRIDINE C14 H10 F N3 BILJSHVAAVZERY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.27 Å
• R-Value Free:  0.241 (Depositor), 0.241 (DCC)
• R-Value Work:  0.190 (Depositor), 0.194 (DCC)
• R-Value Observed: 0.193 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 65.592	α = 90
b = 74.805	β = 90
c = 77.887	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
PDB_EXTRACT	data extraction
autoPROC	data processing
REFMAC	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-04-30
Deposition Author(s): Brunzelle, J.S., Shuvalova, L., Roy, S.M., Watterson, D.M.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-04-30
  Type: Initial release
