29SW | pdb_000029sw

Crystal structure of carbonic anhydrase XII with 3-(benzylsulfonyl)phenyl sulfamate

PDB DOI: https://doi.org/10.2210/pdb29SW/pdb

Classification: LYASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2026-04-07 Released: 2026-10-21
Deposition Author(s): Paketuryte-Latve, V., Smirnov, A., Manakova, E.N., Grazulis, S.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.40 Å
R-Value Free:
0.204 (Depositor), 0.207 (DCC)
R-Value Work:
0.165 (Depositor), 0.174 (DCC)
R-Value Observed:
0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Structure-Affinity and Selectivity of Aryl-Sulfamates as Inhibitors of Carbonic Anhydrase IX

Stancaitis, L., Liberis, M., Baranauskiene, L., Paketuryte-Latve, V., Kvietkauskaite, A., Petrauskas, V., Manakova, E., Smirnov, A., Mickeviciute, A., Juozapaitiene, V., Gedgaudas, M., Kojis, T., Matuliene, J., Grazulis, S., Capkauskaite, E., Matulis, D.

(2026) J Med Chem 69: 22993-23008

DOI: https://doi.org/10.1021/acs.jmedchem.6c02393

Macromolecule Content

Total Structure Weight: 121.61 kDa
Atom Count: 9,196
Modeled Residue Count: 1,043
Deposited Residue Count: 1,052
Unique protein chains: 1

Macromolecules

Find similar proteins by:

| 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Carbonic anhydrase 12	A, B, C, D	263	Homo sapiens	Mutation(s): 0 Gene Names: CA12 EC: 4.2.1.1
UniProt & NIH Common Fund Data Resources
Find proteins for O43570 (Homo sapiens) Explore O43570 Go to UniProtKB: O43570
PHAROS: O43570 GTEx: ENSG00000074410
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O43570
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1J4I( Subject of Investigation/LOI) Query on A1J4I Download:Ideal Coordinates CCD File SDF format, chain G [auth A] SDF format, chain K [auth B] SDF format, chain R [auth D] SDF format, chain N [auth C] MOL2 format, chain G [auth A] MOL2 format, chain K [auth B] MOL2 format, chain R [auth D] MOL2 format, chain N [auth C] mmCIF format, chain G [auth A] mmCIF format, chain K [auth B] mmCIF format, chain R [auth D] mmCIF format, chain N [auth C]	G [auth A], K [auth B], N [auth C], R [auth D]	[3-(phenylmethyl)sulfonylphenyl] sulfamate C₁₃ H₁₃ N O₅ S₂ UVNCVDVYNKEGSN-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain R [auth D] Interactions & Density Focus chain G [auth A] Focus chain K [auth B] Focus chain N [auth C] Focus chain R [auth D]
ZN Query on ZN Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain O [auth D] SDF format, chain L [auth C] SDF format, chain H [auth B] MOL2 format, chain E [auth A] MOL2 format, chain O [auth D] MOL2 format, chain L [auth C] MOL2 format, chain H [auth B] mmCIF format, chain E [auth A] mmCIF format, chain O [auth D] mmCIF format, chain L [auth C] mmCIF format, chain H [auth B]	E [auth A], H [auth B], L [auth C], O [auth D]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Focus chain L [auth C] Focus chain O [auth D] Interactions & Density Focus chain E [auth A] Focus chain H [auth B] Focus chain L [auth C] Focus chain O [auth D]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain M [auth C] SDF format, chain Q [auth D] SDF format, chain P [auth D] SDF format, chain J [auth B] SDF format, chain F [auth A] MOL2 format, chain I [auth B] MOL2 format, chain M [auth C] MOL2 format, chain Q [auth D] MOL2 format, chain P [auth D] MOL2 format, chain J [auth B] MOL2 format, chain F [auth A] mmCIF format, chain I [auth B] mmCIF format, chain M [auth C] mmCIF format, chain Q [auth D] mmCIF format, chain P [auth D] mmCIF format, chain J [auth B] mmCIF format, chain F [auth A]	F [auth A] I [auth B] J [auth B] M [auth C] P [auth D] F [auth A], I [auth B], J [auth B], M [auth C], P [auth D], Q [auth D]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain F [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Focus chain Q [auth D] Interactions & Density Focus chain F [auth A] Focus chain I [auth B] Focus chain J [auth B] Focus chain M [auth C] Focus chain P [auth D] Focus chain Q [auth D]
