2DFD | pdb_00002dfd

Crystal Structure of Human Malate Dehydrogenase Type 2

PDB DOI: https://doi.org/10.2210/pdb2DFD/pdb

Classification: OXIDOREDUCTASE
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2006-02-28 Released: 2006-03-28
Deposition Author(s): Ugochukwu, E., Shafqat, N., Rojkova, A., Sundstrom, M., Arrowsmith, C., Weigelt, J., Edwards, A., von Delft, F., Oppermann, U., Structural Genomics Consortium (SGC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free:
0.194 (Depositor), 0.200 (DCC)
R-Value Work:
0.156 (Depositor), 0.163 (DCC)
R-Value Observed:
0.158 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 2.0 of the entry. See complete history.

Literature

Crystal Structure of Human Malate Dehydrogenase Type 2

Ugochukwu, E., Shafqat, N., Rojkova, A., Sundstrom, M., Arrowsmith, C., Weigelt, J., Edwards, A., von Delft, F., Oppermann, U.

To be published.

Macromolecule Content

Total Structure Weight: 148.97 kDa
Atom Count: 10,300
Modeled Residue Count: 1,256
Deposited Residue Count: 1,368
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Malate dehydrogenase	A, B, C, D	342	Homo sapiens	Mutation(s): 0 Gene Names: MDH2 EC: 1.1.1.37
UniProt & NIH Common Fund Data Resources
Find proteins for P40926 (Homo sapiens) Explore P40926 Go to UniProtKB: P40926
PHAROS: P40926 GTEx: ENSG00000146701
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P40926
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAD Query on NAD Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain M [auth B] SDF format, chain R [auth C] SDF format, chain W [auth D] MOL2 format, chain H [auth A] MOL2 format, chain M [auth B] MOL2 format, chain R [auth C] MOL2 format, chain W [auth D] mmCIF format, chain H [auth A] mmCIF format, chain M [auth B] mmCIF format, chain R [auth C] mmCIF format, chain W [auth D]	H [auth A], M [auth B], R [auth C], W [auth D]	NICOTINAMIDE-ADENINE-DINUCLEOTIDE C₂₁ H₂₇ N₇ O₁₄ P₂ BAWFJGJZGIEFAR-NNYOXOHSSA-N		Interactions Focus chain H [auth A] Focus chain M [auth B] Focus chain R [auth C] Focus chain W [auth D] Interactions & Density Focus chain H [auth A] Focus chain M [auth B] Focus chain R [auth C] Focus chain W [auth D]
HIS Query on HIS Download Ideal Coordinates CCD File SDF format, chain I [auth A] SDF format, chain N [auth B] SDF format, chain S [auth C] MOL2 format, chain I [auth A] MOL2 format, chain N [auth B] MOL2 format, chain S [auth C] mmCIF format, chain I [auth A] mmCIF format, chain N [auth B] mmCIF format, chain S [auth C]	I [auth A], N [auth B], S [auth C]	HISTIDINE C₆ H₁₀ N₃ O₂ HNDVDQJCIGZPNO-YFKPBYRVSA-O		Interactions Focus chain I [auth A] Focus chain N [auth B] Focus chain S [auth C] Interactions & Density Focus chain I [auth A] Focus chain N [auth B] Focus chain S [auth C]
LMR Query on LMR Download Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain K [auth B] SDF format, chain O [auth C] SDF format, chain T [auth D] MOL2 format, chain E [auth A] MOL2 format, chain K [auth B] MOL2 format, chain O [auth C] MOL2 format, chain T [auth D] mmCIF format, chain E [auth A] mmCIF format, chain K [auth B] mmCIF format, chain O [auth C] mmCIF format, chain T [auth D]	E [auth A], K [auth B], O [auth C], T [auth D]	(2S)-2-hydroxybutanedioic acid C₄ H₆ O₅ BJEPYKJPYRNKOW-REOHCLBHSA-N		Interactions Focus chain E [auth A] Focus chain K [auth B] Focus chain O [auth C] Focus chain T [auth D] Interactions & Density Focus chain E [auth A] Focus chain K [auth B] Focus chain O [auth C] Focus chain T [auth D]
ALA Query on ALA Download Ideal Coordinates CCD File SDF format, chain J [auth A] MOL2 format, chain J [auth A] mmCIF format, chain J [auth A]	J [auth A]	ALANINE C₃ H₇ N O₂ QNAYBMKLOCPYGJ-REOHCLBHSA-N		Interactions Focus chain J [auth A] Interactions & Density Focus chain J [auth A]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain L [auth B] SDF format, chain P [auth C] SDF format, chain Q [auth C] SDF format, chain U [auth D] SDF format, chain V [auth D] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain L [auth B] MOL2 format, chain P [auth C] MOL2 format, chain Q [auth C] MOL2 format, chain U [auth D] MOL2 format, chain V [auth D] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain L [auth B] mmCIF format, chain P [auth C] mmCIF format, chain Q [auth C] mmCIF format, chain U [auth D] mmCIF format, chain V [auth D]	F [auth A] G [auth A] L [auth B] P [auth C] Q [auth C] F [auth A], G [auth A], L [auth B], P [auth C], Q [auth C], U [auth D], V [auth D]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain U [auth D] Focus chain V [auth D] Interactions & Density Focus chain F [auth A] Focus chain G [auth A] Focus chain L [auth B] Focus chain P [auth C] Focus chain Q [auth C] Focus chain U [auth D] Focus chain V [auth D]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.90 Å
R-Value Free: 0.194 (Depositor), 0.200 (DCC)
R-Value Work: 0.156 (Depositor), 0.163 (DCC)
R-Value Observed: 0.158 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 59.943	α = 90
b = 152.526	β = 90
c = 154.827	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
MOSFLM	data reduction
CCP4	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History

Deposition Data

Released Date: 2006-03-28

Deposition Author(s):

Structural Genomics Consortium (SGC)

Revision History (Full details and data files)

Version 1.0: 2006-03-28
Type: Initial release
Version 1.1: 2008-04-30
Changes: Version format compliance
Version 1.2: 2011-07-13
Changes: Advisory, Version format compliance
Version 1.3: 2023-10-25
Changes: Data collection, Database references, Derived calculations, Refinement description
Version 2.0: 2025-10-29
Changes: Atomic model, Data collection, Derived calculations, Non-polymer description, Structure summary
