9CYH | pdb_00009cyh

Cryo-EM structure of DA03E17 Fab in complex with influenza virus neuraminidase from B/Colorado/06/2017


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.47 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structural basis of broad protection against influenza virus by human antibodies targeting the neuraminidase active site via a recurring motif in CDR H3.

Jo, G.Yamayoshi, S.Ma, K.M.Swanson, O.Torres, J.L.Ferguson, J.A.Fernandez-Quintero, M.L.Huang, J.Copps, J.Rodriguez, A.J.Steichen, J.M.Kawaoka, Y.Han, J.Ward, A.B.

(2025) Nat Commun 16: 7067-7067

  • DOI: https://doi.org/10.1038/s41467-025-62174-2
  • Primary Citation of Related Structures:
    9CYE, 9CYF, 9CYG, 9CYH, 9CYI, 9CYJ, 9O4N, 9O4O, 9O4P, 9O4Q

  • PubMed Abstract:

    Influenza viruses evolve rapidly, driving seasonal epidemics and posing global pandemic threats. While neuraminidase (NA) has emerged as a vaccine target, shared molecular features of NA antibody responses are still not well understood. Here, we describe cryo-electron microscopy structures of the broadly protective human antibody DA03E17, which was previously identified from an H1N1-infected donor, in complex with NA from A/H1N1, A/H3N2, and B/Victoria-lineage viruses. DA03E17 targets the highly conserved NA active site using its long CDR H3, which features a DR (Asp-Arg) motif that engages catalytic residues and mimics sialic acid interactions. We further demonstrate that this motif is conserved among several NA active site-targeting antibodies, indicating a common receptor mimicry strategy. We also identified BCR sequences containing this DR motif across all donors in a healthy human repertoire database, suggesting that such precursors may be relatively common and have vaccine targeting potential. Our findings reveal shared molecular features in NA active site-targeting antibodies that can be harnessed to design broad, immune-focused influenza vaccines.


  • Organizational Affiliation
    • Department of Integrative Structural and Computational Biology, The Scripps Research Institute, La Jolla, CA, USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
DA03E17 Fab heavy chainA [auth H],
D [auth E],
G [auth F],
J [auth G]
231Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DA03E17 Fab light chainB [auth L],
E [auth I],
H [auth J],
K
215Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
NeuraminidaseC [auth A],
F [auth B],
I [auth C],
L [auth D]
482Influenza B virus (B/Colorado/06/2017)Mutation(s): 0
Gene Names: NA
EC: 3.2.1.18
UniProt
Find proteins for A0A1X9RX69 (Influenza B virus)
Explore A0A1X9RX69
Go to UniProtKB:  A0A1X9RX69
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupA0A1X9RX69
Glycosylation
Glycosylation Sites: 2
Sequence Annotations
Expand
  • Reference Sequence
Oligosaccharides

Help

Entity ID: 4
MoleculeChains Length2D Diagram Glycosylation3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose
M, N, O, P, Q
M, N, O, P, Q, R, S, T
2N-Glycosylation
Glycosylation Resources
GlyTouCan:  G42666HT
GlyCosmos:  G42666HT
GlyGen:  G42666HT
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.47 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX
RECONSTRUCTIONcryoSPARC4.2.1

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States75N93019C00051

Revision History  (Full details and data files)

  • Version 1.0: 2025-08-13
    Type: Initial release
