9I23 | pdb_00009i23

Structure of Human helicase RecQ1- 795-2T G-quadruplex - ADP complex


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.69 Å
  • R-Value Free:
    0.258 (Depositor), 0.258 (DCC)
  • R-Value Work:
    0.244 (Depositor), 0.246 (DCC)
  • R-Value Observed:
    0.244 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.0 of the entry. See complete history


Literature

Structural mechanism of RECQ1 helicase in unfolding G-quadruplexes compared with duplex DNA.

Song, Z.Y.Zhang, X.Ai, X.Huang, L.Y.Hou, X.M.Fosse, P.Liu, N.N.Mauffret, O.Rety, S.Xi, X.G.

(2025) Nucleic Acids Res 53

  • DOI: https://doi.org/10.1093/nar/gkaf877
  • Primary Citation of Related Structures:
    9I0S, 9I16, 9I1P, 9I22, 9I23

  • PubMed Abstract:

    RECQ1, the most abundant RecQ helicase in human cells, is involved in telomere maintenance in ALT cells and plays a critical role in maintaining genomic integrity and stability. Here, we present five high-resolution crystal structures that systematically reveal a novel mechanism by which the RECQ1 helicase recognizes and regulates G-quadruplex (G4) DNA structures. Our results demonstrate that DNA binding induces intra-subunit rearrangement in RECQ1, transitioning it from a closed to an open conformation. This rearrangement alters the stability of the dimer interface. G4 recognition and unwinding are driven by coordinated interactions between the D1/D2 domains and the single-stranded DNA (ssDNA)-binding channel. This dual engagement aligns the G4 tetrad in a geometry favorable for unwinding. ATP hydrolysis facilitates ssDNA translocation, positioning the β-hairpin to disrupt hydrogen bonds-unraveling G4 structures in a manner analogous to the unwinding of dsDNA. This study proposes a mechanistic model for RECQ1-mediated G4 unwinding and elucidates how RECQ1 recognizes and unwinds distinct DNA structures.


  • Organizational Affiliation
    • College of Life Sciences, Northwest A&F University, Yangling, 712100 Shaanxi, China.

Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
ATP-dependent DNA helicase Q1
A, B
531Homo sapiensMutation(s): 0
Gene Names: RECQLRECQ1RECQL1
EC: 5.6.2.4
UniProt & NIH Common Fund Data Resources
Find proteins for P46063 (Homo sapiens)
Explore P46063
Go to UniProtKB:  P46063
PHAROS:  P46063
GTEx:  ENSG00000004700
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP46063
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
DNA (5'-D(P*GP*GP*GP*TP*GP*GP*GP*TP*GP*GP*GP*TP*GP*GP*GP*T)-3')
C, D
23Homo sapiens
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ADP (Subject of Investigation/LOI)
Query on ADP

Download Ideal Coordinates CCD File
F [auth A],
I [auth B]
ADENOSINE-5'-DIPHOSPHATE
C10 H15 N5 O10 P2
XTWYTFMLZFPYCI-KQYNXXCUSA-N
ZN (Subject of Investigation/LOI)
Query on ZN

Download Ideal Coordinates CCD File
E [auth A],
H [auth B]
ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
K
Query on K

Download Ideal Coordinates CCD File
K [auth C],
L [auth C],
M [auth D],
N [auth D]
POTASSIUM ION
K
NPYPAHLBTDXSSS-UHFFFAOYSA-N
MG (Subject of Investigation/LOI)
Query on MG

Download Ideal Coordinates CCD File
G [auth A],
J [auth B]
MAGNESIUM ION
Mg
JLVVSXFLKOJNIY-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.69 Å
  • R-Value Free:  0.258 (Depositor), 0.258 (DCC)
  • R-Value Work:  0.244 (Depositor), 0.246 (DCC)
  • R-Value Observed: 0.244 (Depositor)
Space Group: P 41 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 155.659α = 90
b = 155.659β = 90
c = 129.566γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
autoPROCdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32301042, 32071291, 32071225

Revision History  (Full details and data files)

  • Version 1.0: 2025-10-01
    Type: Initial release
