9SYM | pdb_00009sym

Structure of human DNMT2 with bound competitive inhibitor

PDB DOI: https://doi.org/10.2210/pdb9SYM/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-10-13 Released: 2026-10-28
Deposition Author(s): Schwan, M., Kopp, J., Sinning, I.
Funding Organization(s): German Research Foundation (DFG)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free:
0.215 (Depositor), 0.215 (DCC)
R-Value Work:
0.176 (Depositor), 0.176 (DCC)
R-Value Observed:
0.178 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9SYM

This is version 1.0 of the entry. See complete history.

Literature

Structure of human DNMT2 with bound competitive inhibitor

Schwan, M., Kopp, J., Sinning, I.

To be published.

Macromolecule Content

Total Structure Weight: 40.98 kDa
Atom Count: 2,822
Modeled Residue Count: 322
Deposited Residue Count: 348
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
tRNA (cytosine(38)-C(5))-methyltransferase	A	348	Homo sapiens	Mutation(s): 0 Gene Names: TRDMT1, DNMT2 EC: 2.1.1.204
UniProt & NIH Common Fund Data Resources
Find proteins for O14717 (Homo sapiens) Explore O14717 Go to UniProtKB: O14717
PHAROS: O14717 GTEx: ENSG00000107614
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O14717
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 5 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1JR0( Subject of Investigation/LOI) Query on A1JR0 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	(2~{S})-4-[[(2~{R},3~{S},4~{R},5~{R})-5-(6-aminopurin-9-yl)-3,4-bis(oxidanyl)oxolan-2-yl]methyl-[3-(4-azanyl-2-oxidanylidene-1~{H}-pyrimidin-5-yl)propyl]amino]-2-azanyl-butanoic acid C₂₁ H₃₀ N₁₀ O₆ GLZROOYWSDINLD-QTOWJTHWSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain F [auth A] SDF format, chain E [auth A] SDF format, chain D [auth A] MOL2 format, chain F [auth A] MOL2 format, chain E [auth A] MOL2 format, chain D [auth A] mmCIF format, chain F [auth A] mmCIF format, chain E [auth A] mmCIF format, chain D [auth A]	D [auth A], E [auth A], F [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Interactions & Density Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A]
GOL Query on GOL Download:Ideal Coordinates CCD File SDF format, chain G [auth A] MOL2 format, chain G [auth A] mmCIF format, chain G [auth A]	G [auth A]	GLYCEROL C₃ H₈ O₃ PEDCQBHIVMGVHV-UHFFFAOYSA-N		Interactions Focus chain G [auth A] Interactions & Density Focus chain G [auth A]
GLY Query on GLY Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	GLYCINE C₂ H₅ N O₂ DHMQDGOQFOQNFH-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain H [auth A] MOL2 format, chain H [auth A] mmCIF format, chain H [auth A]	H [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Interactions & Density Focus chain H [auth A]

Modified Residues 1 Unique
ID	Chains	Modified Residue	Modification Type	Formula	2D Diagram
CME Query on CME	A	CYS	Beta-mercaptoethanol	C₅ H₁₁ N O₃ S₂

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.00 Å
R-Value Free: 0.215 (Depositor), 0.215 (DCC)
R-Value Work: 0.176 (Depositor), 0.176 (DCC)
R-Value Observed: 0.178 (Depositor)

Space Group: I 4₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 116.464	α = 90
b = 116.464	β = 90
c = 70.226	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-10-28

Deposition Author(s):

Funding Organization	Location	Grant Number
German Research Foundation (DFG)	Germany	TRR319

Revision History (Full details and data files)

Version 1.0: 2026-10-28
Type: Initial release
