9T29 | pdb_00009t29

Jumonji domain-containing protein 2D with crystallization epitope mutation Q41R

• PDB DOI: https://doi.org/10.2210/pdb9T29/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2025-10-22 Released: 2025-11-26
• Deposition Author(s): Fairhead, M., Strain-Damerell, C., Ye, M., Mackinnon, S.R., Pinkas, D., MacLean, E.M., Koekemoer, L., Damerell, D., Krojer, T., Arrowsmith, C.H., Edwards, A., Bountra, C., Yue, W., Burgess-Brown, N., Marsden, B., von Delft, F.
• Funding Organization(s): The Structural Genomics Consortium (SGC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:
  0.250 (Depositor), 0.227 (DCC)
• R-Value Work:
  0.225 (Depositor), 0.212 (DCC)
• R-Value Observed:
  0.226 (Depositor)

Starting Model: experimental

Literature

A fast, parallel method for efficiently exploring crystallization behaviour of large numbers of protein variants

Fairhead, M., Strain-Damerell, C., Ye, M., Mackinnon, S.R., Pinkas, D., MacLean, E.M., Koekemoer, L., Damerell, D., Krojer, T., Arrowsmith, C.H., Edwards, A., Bountra, C., Yue, W., Burgess-Brown, N., Marsden, B., von Delft, F.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 39.73 kDa
• Atom Count: 2,759
• Modeled Residue Count: 331
• Deposited Residue Count: 343
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Lysine-specific demethylase 4D	A	343	Homo sapiens	Mutation(s): 1  Gene Names: KDM4D, JHDM3D, JMJD2D EC: 1.14.11.66
UniProt & NIH Common Fund Data Resources
Find proteins for Q6B0I6 (Homo sapiens) Explore Q6B0I6  Go to UniProtKB:  Q6B0I6
PHAROS:  Q6B0I6 GTEx:  ENSG00000186280

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	B [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N
NI	C [auth A]	NICKEL (II) ION Ni VEQPNABPJHWNSG-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.01 Å
• R-Value Free:  0.250 (Depositor), 0.227 (DCC)
• R-Value Work:  0.225 (Depositor), 0.212 (DCC)
• R-Value Observed: 0.226 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 73.167	α = 90
b = 73.167	β = 90
c = 134.44	γ = 120

Software Package:

Software Name	Purpose
BUSTER	refinement
xia2	data reduction
xia2	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-11-26
Deposition Author(s): Fairhead, M., Strain-Damerell, C., Ye, M., Mackinnon, S.R., Pinkas, D., MacLean, E.M., Koekemoer, L., Damerell, D., Krojer, T., Arrowsmith, C.H., Edwards, A., Bountra, C., Yue, W., Burgess-Brown, N., Marsden, B., von Delft, F.

---

Funding Organization	Location	Grant Number
The Structural Genomics Consortium (SGC)	Canada	--

Revision History

• Version 1.0: 2025-11-26
  Type: Initial release
