9X8W | pdb_00009x8w

Crystal structure of Cell division control protein 42 homolog

• PDB DOI: https://doi.org/10.2210/pdb9X8W/pdb

• Classification: CELL CYCLE
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2025-10-20 Released: 2026-10-28
• Deposition Author(s): Xiqo, Q.J., Qing, W.M., Zhang, J.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:
  0.282 (Depositor), 0.280 (DCC)
• R-Value Work:
  0.216 (Depositor), 0.222 (DCC)
• R-Value Observed:
  0.223 (Depositor)

Starting Model: experimental

Literature

The crysal structure of Cell division control protein 42 homolog

Xiao, Q.J., Qing, W.M., Zahng, J.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 43.6 kDa
• Atom Count: 2,985
• Modeled Residue Count: 374
• Deposited Residue Count: 382
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Cell division control protein 42 homolog	A, B	191	Homo sapiens	Mutation(s): 0  Gene Names: CDC42 EC: 3.6.5.2
UniProt & NIH Common Fund Data Resources
Find proteins for P60953 (Homo sapiens) Explore P60953  Go to UniProtKB:  P60953
PHAROS:  P60953 GTEx:  ENSG00000070831

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GDP	E [auth A], G [auth B]	GUANOSINE-5'-DIPHOSPHATE C10 H15 N5 O11 P2 QGWNDRXFNXRZMB-UUOKFMHZSA-N
SO4	C [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
MG	D [auth A], F [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.90 Å
• R-Value Free:  0.282 (Depositor), 0.280 (DCC)
• R-Value Work:  0.216 (Depositor), 0.222 (DCC)
• R-Value Observed: 0.223 (Depositor)

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 97.007	α = 90
b = 97.007	β = 90
c = 107.401	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
PDB_EXTRACT	data extraction
HKL-3000	data reduction
HKL-3000	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-10-28
Deposition Author(s): Xiqo, Q.J., Qing, W.M., Zhang, J.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2026-10-28
  Type: Initial release
