9XCS | pdb_00009xcs

Cryo-EM structure of HalTWT, a peptidase-domain containing ABC Transporter, with ADP and vanadate

PDB DOI: https://doi.org/10.2210/pdb9XCS/pdb
EM Map EMD-66742: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Halalkalibacterium halodurans C-125
Expression System: Escherichia coli 'BL21-Gold(DE3)pLysS AG
Mutation(s): No

Deposited: 2025-10-26 Released: 2026-10-28
Deposition Author(s): Gan, B.K., Luo, M.
Funding Organization(s): Ministry of Education (MoE, Singapore)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.38 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9XCS

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of HalTWT, a peptidase-domain containing ABC Transporter, with ADP and vanadate

Gan, B.K., Luo, M.

To be published.

Macromolecule Content

Total Structure Weight: 166.46 kDa
Atom Count: 9,036
Modeled Residue Count: 1,130
Deposited Residue Count: 1,448
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Peptidase C39	A, B	724	Halalkalibacterium halodurans C-125	Mutation(s): 0 Gene Names: AMD02_16410
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ADP (Subject of Investigation/LOI) Query on ADP Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth B] MOL2 format, chain D [auth A] MOL2 format, chain G [auth B] mmCIF format, chain D [auth A] mmCIF format, chain G [auth B]	D [auth A], G [auth B]	ADENOSINE-5'-DIPHOSPHATE C₁₀ H₁₅ N₅ O₁₀ P₂ XTWYTFMLZFPYCI-KQYNXXCUSA-N		Interactions Focus chain D [auth A] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain G [auth B]
VO4 (Subject of Investigation/LOI) Query on VO4 Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain F [auth B] MOL2 format, chain C [auth A] MOL2 format, chain F [auth B] mmCIF format, chain C [auth A] mmCIF format, chain F [auth B]	C [auth A], F [auth B]	VANADATE ION O₄ V LSGOVYNHVSXFFJ-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain F [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B]
MG (Subject of Investigation/LOI) Query on MG Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain H [auth B] MOL2 format, chain E [auth A] MOL2 format, chain H [auth B] mmCIF format, chain E [auth A] mmCIF format, chain H [auth B]	E [auth A], H [auth B]	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain H [auth B] Interactions & Density Focus chain E [auth A] Focus chain H [auth B]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.38 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.19.2_4158
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-10-28

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Education (MoE, Singapore)	Singapore	--

Revision History (Full details and data files)

Version 1.0: 2026-10-28
Type: Initial release
