9Z2Z | pdb_00009z2z

Crystal structure of Glutamate-tRNA synthetase GluRS from Chlamydia pneumoniae in complex with O5'-(L-GLUTAMYL-SULFAMOYL)-ADENOSINE

• PDB DOI: https://doi.org/10.2210/pdb9Z2Z/pdb

• Classification: LIGASE
• Organism(s): Chlamydia pneumoniae
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2025-11-05 Released: 2025-11-26
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:
  0.254 (Depositor), 0.252 (DCC)
• R-Value Work:
  0.233 (Depositor), 0.235 (DCC)
• R-Value Observed:
  0.234 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Glutamate-tRNA synthetase GluRS from Chlamydia pneumoniae in complex with O5'-(L-GLUTAMYL-SULFAMOYL)-ADENOSINE

Liu, L., Lovell, S., Enayati, P., Battaile, K.P.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 122.16 kDa
• Atom Count: 7,646
• Modeled Residue Count: 954
• Deposited Residue Count: 1,052
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutamate--tRNA ligase	A, B	526	Chlamydia pneumoniae	Mutation(s): 0  Gene Names: gltX, CPn_0560, CP_0190, CpB0582 EC: 6.1.1.17
UniProt
Find proteins for Q9Z7Z3 (Chlamydia pneumoniae) Explore Q9Z7Z3  Go to UniProtKB:  Q9Z7Z3

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GSU (Subject of Investigation/LOI)	C [auth A], F [auth B]	O5'-(L-GLUTAMYL-SULFAMOYL)-ADENOSINE C15 H21 N7 O9 S YBRKRYFZKHICLS-WERHYGNASA-N
CL	D [auth A], E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.80 Å
• R-Value Free:  0.254 (Depositor), 0.252 (DCC)
• R-Value Work:  0.233 (Depositor), 0.235 (DCC)
• R-Value Observed: 0.234 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 56.009	α = 90
b = 132.244	β = 107.42
c = 92.721	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-11-26
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394

Revision History

• Version 1.0: 2025-11-26
  Type: Initial release
