9A56 | pdb_00009a56

Integrative model of RPOB-NUSG by crosslinking MS and deep learning

Integrative structure models are generated using different types of input information, including varied experimental data, physical principles, statistical preferences, and other prior information.


Integrative Structure Snapshot

  • Multi-Scale: No
  • Multi-State: No
  • Ordered-State: No
  • Deposited Models: 1
  • Representative Model: 1

This is version 1.0 of the entry. See complete history


Literature

Modelling protein complexes with crosslinking mass spectrometry and deep learning

Stahl, K.Warneke, R.Demann, L.Bremenkamp, R.Hormes, B.Brock, O.Stulke, J.Rappsilber, J.

(2024) Nat Commun 15: 7866

  • DOI: https://doi.org/10.1038/s41467-024-51771-2
  • Primary Citation of Related Structures:
    9A40, 9A4A, 9A4B, 9A4C, 9A4D, 9A4E, 9A4F, 9A4G, 9A4H, 9A4I, 9A4J, 9A4K, 9A4L, 9A4M, 9A4N, 9A4O, 9A4P, 9A4Q, 9A4R, 9A4S, 9A4T, 9A4U, 9A4V, 9A4W, 9A4X, 9A4Y, 9A4Z, 9A50, 9A51, 9A52, 9A53, 9A54, 9A55, 9A56, 9A57, 9A58, 9A59, 9A5A, 9A5B, 9A5C, 9A5D, 9A5E, 9A5F, 9A5G, 9A5H, 9A5I, 9A5J, 9A5K, 9A5L, 9A5M

  • PubMed Abstract:

    Scarcity of structural and evolutionary information on protein complexes poses a challenge to deep learning-based structure modelling. We integrate experimental distance restraints obtained by crosslinking mass spectrometry (MS) into AlphaFold-Multimer, by extending AlphaLink to protein complexes. Integrating crosslinking MS data substantially improves modelling performance on challenging targets, by helping to identify interfaces, focusing sampling, and improving model selection. This extends to single crosslinks from whole-cell crosslinking MS, opening the possibility of whole-cell structural investigations driven by experimental data. We demonstrate this by revealing the molecular basis of iron homoeostasis in Bacillus subtilis.


  • Organizational Affiliation
    • Technische Universität Berlin, Chair of Bioanalytics, Berlin, Germany.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RPOB_BACSU1,193Bacillus subtilis (strain 168)Mutation(s): 0
Gene Names: rpoB
EC: 2.7.7.6
UniProt
Find proteins for P37870 (Bacillus subtilis (strain 168))
Explore P37870
Go to UniProtKB:  P37870
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP37870
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
NUSG_BACSU177Bacillus subtilis (strain 168)Mutation(s): 0
Gene Names: nusG
UniProt
Find proteins for Q06795 (Bacillus subtilis (strain 168))
Explore Q06795
Go to UniProtKB:  Q06795
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ06795
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Integrative Structure Snapshot

  • Multi-Scale: No
  • Multi-State: No
  • Ordered-State: No
  • Deposited Models: 1
  • Representative Model: 1

Structure Validation

View Full Validation Report

View Summary Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2024-09-18
    Type: Initial release
