9C4X | pdb_00009c4x

Menin mutant - M327I

• PDB DOI: https://doi.org/10.2210/pdb9C4X/pdb

• Classification: PROTEIN BINDING
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): Yes


• Deposited: 2024-06-05 Released: 2025-05-14
• Deposition Author(s): Clegg, B.D., Cierpicki, T., Grembecka, J.
• Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.58 Å
• R-Value Free:
  0.194 (Depositor), 0.195 (DCC)
• R-Value Work:
  0.161 (Depositor), 0.162 (DCC)

Starting Model: experimental

Literature

Menin mutant M327I

Clegg, B.D., Cierpicki, T., Grembecka, J.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by (software)

Macromolecule Content

• Total Structure Weight: 55.36 kDa
• Atom Count: 4,229
• Modeled Residue Count: 469
• Deposited Residue Count: 489
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Menin	A	489	Homo sapiens	Mutation(s): 2  Gene Names: MEN1, SCG2
UniProt & NIH Common Fund Data Resources
Find proteins for O00255 (Homo sapiens) Explore O00255  Go to UniProtKB:  O00255
PHAROS:  O00255 GTEx:  ENSG00000133895

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
PG4	B [auth A], E [auth A]	TETRAETHYLENE GLYCOL C8 H18 O5 UWHCKJMYHZGTIT-UHFFFAOYSA-N
PEG	C [auth A], D [auth A], F [auth A]	DI(HYDROXYETHYL)ETHER C4 H10 O3 MTHSVFCYNBDYFN-UHFFFAOYSA-N
SO4	G [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.58 Å
• R-Value Free:  0.194 (Depositor), 0.195 (DCC)
• R-Value Work:  0.161 (Depositor), 0.162 (DCC)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49	α = 90
b = 80.203	β = 90
c = 124.65	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
HKL-2000	data reduction
HKL-2000	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-05-14
Deposition Author(s): Clegg, B.D., Cierpicki, T., Grembecka, J.

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	272561

Revision History

• Version 1.0: 2025-05-14
  Type: Initial release
